Place of Origin:
Shaanxi, China
Brand Name:
bairui
| Model | LS-3RL |
| Pressure Range | -1-5Bar 0-50 Bar Optional |
| Measuring Depth | 0-150m |
| Overload | 150% F.S. |
| Burst Pressure | 300% F.S. |
| Accuracy | ≤+0.5%F.S; ≤+0.25%F.S; ≤+0.15%F.S Including non-lin., rep. and hys. Optional |
| Long Stability | Standard: 0.1%F.S±0.05%/Year Max: 0.15%F.S±0.05%/Year |
| Working Temperature | -10℃~70℃ |
| Storage Temperature | -20℃~70℃ |
| Outer Shell Material | Compatible with 316 Stainless Steel or Titanium Alloy or PTFE materials |
| Output Options | 4-20 mA or 4-20mA +HART (2 wires) 0-5V/0.5-4.5V/1-5V/0-10V/0-2.5V... (3 wires) RS485 (4 wires) RS485+4-20mA (6 wires) |
| Power Supply | 12~36 Vdc 12~30Vdc/5Vdc/12Vdc 10~30 Vdc 12~30Vdc |
| Insulate Resistance | >100MQ @50V dc |
| Zero Temp. Drift | Typical: 0.05%FS/℃ Max: 0.1%FS/℃ |
| Electronic Connection | Fixed cable and water proof IP68 |
| Response Time | ≤1ms |
| Pressure Type | Gauge pressure |
| Water Proof | IP68 |
| Temperature Range | -30 to 70 Degree C (by customized) |
| Weight | Net weight: 0.30KG, Full Packing weight: 0.5KG (Not Include Cable) |
| Place of Origin | Shaanxi, China |
| Brand | Bairui |
