Place of Origin:
Shaanxi, China
Brand Name:
Bairui Electric
Model Number:
5725
| Installation Mode | Hole mounting |
| Model Number | 5725 |
| Origin | Denmark |
| Brand | PR electronics |
| Feature | Frequency display |
| Sensor Type | All standard sensors |
| Hz, Measuring Range/Minimum Range | 0...50 kHz / 0.001 Hz |
| Minimum Pulse Width | 25 ms |
| RTD, Measuring Range/Minimum Range | 5...17 VDC |
| Display, Number/Type | 4 bit/LED |
| Display, Number Height | 13.8 mm |
| mA, Signal Range/Minimum Range | 0...23 mA / 16 mA |
| Relay | 2 x SPDT, AC: 500 VA |
| Ambient Temperature | -20...+60°C |
| Supply Voltage, General Purpose, AC/DC | 21.6...253 V/19.2...300 V |
| Maximum Power Consumption | 3.6W |
| Isolation Voltage, Test/Work | 2.3 kVAC / 250 VAC |
| Response Time | 1...60 s |
| Precision | < ±0.1% measurement value |
| Temperature Coefficient | < ±0.01% measurement value / °C |
| NAMUR | NE43 |
| Parameter Setting Mode | Panel button |
| Structural Dimension | 48 x 96 x 120 mm |
| Opening Size | 44.5 x 91.5 mm |
| Application Industry | Industry and ship |
