Place of Origin:
Shaanxi, China
Brand Name:
Bairui Electric
Model Number:
4225
| Model Number | 4225 |
| Brand | PR electronics |
| Feature | Frequency transmitter |
| Input | |
| Sensor Type | All standard sensors |
| Hz, Measuring Range/Minimum Range | 0…100 kHz / 0.001 Hz |
| Minimum Pulse Width | 4 µs |
| mA, Signal Range/Minimum Range | 0...23 mA / 16 mA |
| V, Signal Range/Minimum Range | 0…11.5 VDC / 4 VDC |
| Hz, Signal Range/Minimum Range | 0.001Hz…100kHz/0.001Hz |
| Pulse Output | NPN / PNP (4225C) |
| Relay | 1 (4225A) / 2 (4225B) |
| Maximum Output Frequency | 100 kHz |
| Sensor Power Supply | 5…17 VDC |
| Ambient Temperature | -20…+60°C |
| Power Supply Voltage, AC/DC | 21.6...253 V/19.2...300 V |
| Maximum Power Consumption, Single/Dual Channel | 2.6 W |
| Isolation Voltage, Test/Work | 2.3 kVAC / 250 VAC |
| Response Time | < 30 ms |
| Signal Dynamic Range, Input/Output | - / 18 bit |
| Precision | < The range set by 0.06% |
| Temperature Coefficient | 0.006% / C° |
| NAMUR | NE21, NE43 |
| Passage | 1 |
| Parameter Setting Mode | Equipment in the 4500 series |
| Structural Dimension | 109 x 23.5 x 104 mm |
